Hot Sale High Quality Single Beam Overhead Crane

Certification
China Henan Dowell Crane Co., Ltd. certification
China Henan Dowell Crane Co., Ltd. certification
Customer Reviews
Our company is DOWELL's old customer, several years has ordered a double beam overhead crane and single beam bridge crane

—— Sedanur BAYDAR

I'm Online Chat Now

Hot Sale High Quality Single Beam Overhead Crane

Hot Sale High Quality Single Beam Overhead Crane
Hot Sale High Quality Single Beam Overhead Crane
Hot Sale High Quality Single Beam Overhead Crane Hot Sale High Quality Single Beam Overhead Crane Hot Sale High Quality Single Beam Overhead Crane Hot Sale High Quality Single Beam Overhead Crane

Large Image :  Hot Sale High Quality Single Beam Overhead Crane

Product Details:
Place of Origin: China (Mainland)
Brand Name: Dowellcrane
Certification: CE/ISO9001
Model Number: LD
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 20000-80000 /Set
Packaging Details: packed by plywood crate or plastic woven cloth
Delivery Time: 60days
Supply Ability: 1000sets/month

Hot Sale High Quality Single Beam Overhead Crane

Description
Product Name: Hot Sale High Quality Single Beam Overhead Crane Crane Type: Bridge Crane
Capacity: 0.5~32ton Power: 3-Phase AC 380V 50Hz
Power Source: Electric Condition: New
Application: Construction,Workshop,Factory Certification: ISO CE
High Light:

mini lifting crane

,

mini lifting equipment

Hot Sale High Quality Single Beam Overhead Crane



Hot Sale High Quality Single Beam Overhead Crane Description:

LDA model single girder overhead crane is a kind of light duty crane, with a capacity of 1 to 20 tons. The span is 7.5to 31.5 meters. Working grade is A3. Working temperature is -25°C to 40°C.
It is widely used in plants, warehouse, and material stocks to lift goods.
It is matched with electric hoist which is CD model or MD model.
It is prohibited to use the equipment in the combustible, explosive or corrosives environment.



Hot Sale High Quality Single Beam Overhead Crane Drawing

Hot Sale High Quality Single Beam Overhead Crane 0



Hot Sale High Quality Single Beam Overhead Crane Production Feature

  • Overload protection in the event of overload, the hoist unit switches off and only the lowering motion is possible
  • Long and cross travel limited by means of preliminary and final limit switches or Wireless anti-collision device
  • Anti-falling protection for the Three-in-One electric motor of trolley and crane prevents from accidental falling
  • All movements can be switched off by actuating the emergency-off switch at the control station via a main contact
  • High quality long time bearing polyurethane materials buffer fixed at the end of trolley travelling and crane travelling to prevent over traveling
  • Safety hook latch used for avoiding the lifted material out off from the hook
  • Audible and visual alarm device to inform the person stay near by the travelling crane.
  • Rain Cover for lifting mechanism of outdoor cranes, electric cabinet and driving mechanism
  • Protective earth conductor is fitted as standard
  • Voltage lower protection system
  • Current overload protection system



Parameter Data

Specification for Single Beam Overhead Crane
Basic Parameters
Lift capacity
0.5ton-32ton
Lift height
3-30m
Lift height
6-36m
Lifting Mechanism
Lifting speed
0-8m/min
Electrical parts
CHINT or International brand
Paints
Chinese famous brand "Lehua"
Travelling Mechanism
Cross travelling speed
2-20m/min
Long travelling speed
2-20m/min
Mechanism
Chinese famous brand



Production Details

Hot Sale High Quality Single Beam Overhead Crane 1



Certifications

Hot Sale High Quality Single Beam Overhead Crane 2



Our Service

  1. Dowell Crane's aftermarket department provides reliable service worldwide.
  2. Delivery of all spare parts required for preventive and corrective maintenance.
  3. Develop a suitable maintenance and inspection schedule in accordance with local and international regulations.
  4. Having a proper maintenance and inspection schedule, including spare parts inventory, will prevent unplanned crane downtime.
  5. Personal training on product use
