3T Electric Chain Hoist With Trolley For Factory Lifting Equipment

Certification
China Henan Dowell Crane Co., Ltd. certification
China Henan Dowell Crane Co., Ltd. certification
Customer Reviews
Our company is DOWELL's old customer, several years has ordered a double beam overhead crane and single beam bridge crane

—— Sedanur BAYDAR

I'm Online Chat Now

3T Electric Chain Hoist With Trolley For Factory Lifting Equipment

3T Electric Chain Hoist With Trolley For Factory Lifting Equipment
3T Electric Chain Hoist With Trolley For Factory Lifting Equipment
3T Electric Chain Hoist With Trolley For Factory Lifting Equipment 3T Electric Chain Hoist With Trolley For Factory Lifting Equipment

Large Image :  3T Electric Chain Hoist With Trolley For Factory Lifting Equipment

Product Details:
Place of Origin: China (Mainland)
Brand Name: Dowellcrane
Certification: CCC CE ISO SGS
Model Number: chain
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 600-3600USD/set
Packaging Details: Packed by high quality wooden box
Delivery Time: 25days
Supply Ability: 10000sets/year

3T Electric Chain Hoist With Trolley For Factory Lifting Equipment

Description
Sling Type: Chain Lift Speed: Control By Yourself
Warranty: 2 YEAR Application: Lifting Goods
Color: Customised Power Supply: 380V 50Hz Three-phase Or Customer;'s Request
High Light:

electric lifting hoist

,

industrial electric hoist

Factory lifting equipment chain electric hoist 3 ton with trolley





Description:



electric chain hoist 3 ton Absolute reliability is one of the most important features for Pendent control WKTO electric chain hoist. To ensure the highest possible reliability levels in day to day operation, our crane systems are made to the most stringent quality standards. This model crane widely used in factories, mines, Bridges, construction and other work place for materials handling, equipment installation, etc. Especially be suitable for high-rise building construction and welding storage tank with a number of crane.



Parameter Data:



Model

Capacity

(T)

Standard Lift

(m)

Test load

(KN)

Motor power

(KW)

No. of chain

Dia. of chain

(mm)

Speed

(m/min)

N.W.

(kg)

Extra weight per meter of extra lift (kg)
HHBD-0.3A 0.3 3 3.75 1.0 1 6.3 7.8 42 0.5
HHBD-0.5A 0.5 3 6.25 1.1 1 6.3 7.8 42 0.5
HHBD-1.0A 1.0 3 12.5 1.5 1 7.1 6.8 59 1.1
HHBD-2.0A 2.0 3 25 1.5 1 10 6.8 110 2.2
HHBD-3.0A 3.0 3 37.5 3.0 1 11.2 5.6 115 2.9
HHBD-1.0B 1.0 3 12.5 1.5 2 6.3 3.9 47 1.0
HHBD-2.0B 2.0 3 25 1.5 2 7.1 3.4 69 2.2
HHBD-3.0B 3.0 3 37.5 3.0 2 10 5.8 123 4.4
HHBD-5.0B 5.0 3 62.5 3.0 2 11.2 2.8 133



Application places:



1, extensively used in factories, workshops, warehouses and many other occasions to hoist materials directly,

2, installed on the straight or curve I-steel beam of Single-girder Cranes to lift goods.

3, It can also be used together with Electric Hoist Double-beam, gantry crane and slewing cranes to hoist different items and so on.

It has so many appllication usages just for its advantages, such as: tight structure, convenient operation, light weight, wide common use and so on.



Product Details Show:



3T Electric Chain Hoist With Trolley For Factory Lifting Equipment 0





Component:



Shell

It is made of light aluminum alloy shell,light but hard.The cooling fin is specially designed to ensure quick heat dissipation with the rate up to 40% and continous service.The integral enclosed structure is applicable to places like chemical plant and electroplate factory.

Side magnetic braking device

The magnetic orce generator is the latest design which is featured for generating magnetic force.It allows instant brake as soon as the electric power is cut off.Thus the braking safety while loading is guaranteed.

Limit switch

The limit switch device is installed where the weight is lifted on and off to make the motor to stop automatically so as to prohibit the chains from exceeding for safety

Chain

The chain shall adopt the imported FEC80 ultraheat-treatable steel alloy chain.

It can be safely used in poor environments such as rain,sea water and chemicals.

Electromagnetic contactor

Electromagnetic contactor can be used safely under high frequency.

Inverse phase sequence protecting device

It is sepcial electrical installation which controls the circuit not to work in case of wiring error in the power supply.

Gear

The gear made of alloy steel and through the heat treatment.

Protection class(hoist and push bottom):IP54&IP65

Power supply:

phase,200-600v,50/60Hz

ISO:

M4 FEM:1AM(M5 customized available)
