Single Girder Overhead Bridge Crane Travelling 32t Warehouse

Single Girder Overhead Bridge Crane Travelling 32t Warehouse
Single Girder Overhead Bridge Crane Travelling 32t Warehouse
Single Girder Overhead Bridge Crane Travelling 32t Warehouse Single Girder Overhead Bridge Crane Travelling 32t Warehouse Single Girder Overhead Bridge Crane Travelling 32t Warehouse

Large Image :  Single Girder Overhead Bridge Crane Travelling 32t Warehouse

Product Details:
Place of Origin: China (Mainland)
Brand Name: Dowellcrane
Certification: SGS IOS CE
Model Number: LD
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $1000-15000/1 set
Packaging Details: packed by plywood crate or plastic woven cloth
Delivery Time: 40days
Supply Ability: 4500 sets per years

Single Girder Overhead Bridge Crane Travelling 32t Warehouse

Description
Product Name: Warehouse Single Girder Overhead Bridge Crane Supplier Span: 10.5-31.5m
Warranty: 3 Years Condition: New
After-sales Service Provided: Field Installation,Online Support,Free Spare Parts Feature: Bridge Crane
Working Duty: A3-A5 Lifting Speed: 5-15M/MIN
Max. Lifting Load: 32t Color: Customized
High Light:

Single Girder overhead travelling crane

,

32t Overhead Bridge Crane

,

Warehouse Overhead Bridge Crane

Warehouse Single Girder Overhead Bridge Crane Supplier





Warehouse Single Girder Overhead Bridge Crane Supplier Description



LD Single Girder Overhead Crane are widely used for lifting goods in factories, warehouses, and material plants. It has a reasonable structure and high overall steel strength. It is usually used in conjunction with CD and MD electric hoists. This kind of equipment is forbidden to be used in flammable, explosive and corrosive environments.



Single Girder Overhead Bridge Crane Travelling 32t Warehouse 0



Application of Warehouse Single Girder Overhead Bridge Crane Supplier



LD Single Girder Overhead Crane is an ideal choice for workshops, warehouses, material yards, and manufacturing and production facilities. It is suitable for facilities with low headroom and saves space. It is usually used in steel plants, plastic plants, railways, buildings and other places.



Warehouse Single Girder Overhead Bridge Crane Supplier Parameter



Specific Parameters


Crane traveling mechanism
WorKing speed(m/min)
20 Ground
Speed ratio
58.78

Motor
Type
YSE90L-4

Power(Kw)
4*1.5
Rotation speed(n/min)
7.5≤S≤31.5
Lifting Machanism(electric hoist)&electric hoist traveling mechanism
Model ofelectric hoist
CD1Model
MD1Model
Lifting speed(m/min)
3.5
3.5/0.35
H Hoisting height(m)
9,12.,18,24,30
Traveling speed(m/min)
20
motor
Cone squirrel-cage model
Working class
A3
Electric current
380V 50Hz three-phase
Wheel diameter
Φ270
Φ370
Width of track
51~70mm









Benefits & Features



  • Lightweight structure, excellent performance, advanced design concept, effectively improve space utilization.
  • Made of high quality steel, durable and corrosion resistant.
  • Complete standard configuration, stable running, fast positioning, stable and safe operation.
  • Simple maintenance, low installation and maintenance costs, and long service life.​



Electric Parts

  • Hoist and crane is controlled separately, and can move together and separately.
  • Flat cable or special cable power supply for electric hoist
  • Galvanize slide and cable small trolley
  • Smoothly moving, overall aesthetics
  • Set electric taxi speed is high, ensure continuing power supply,
  • Operation, hoisting, the point start special smoothly,
  • Users can choose according to different needs.

Packing and Delivery



Single Girder Overhead Bridge Crane Travelling 32t Warehouse 1



Our Service



  • All the machines will be full tested before shipment
  • Technical supports and suggestions before you order a machine according to your work place.
  • Professional opertion instruction of the machine.
  • 24 months warranty period and we will provide the consumable parts at cost price after the warranty period.
  • 24-hour technical support by emails, calling or videos.



FAQ



Q1: What's the information should I provide when inquiry?A1: More details or drawings, better.
A1: Lift capacity B: span C: lift height D: power source or other specials you give us will be more appreciated.
Q2: Can this type work in hazardous environment?
A2: Sure! We can customize for you, acid proof or explosion proof, no problem for that.
Q3: Can you provide the various lifting tools?
A3: Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
