Industrial 15m Gantry Crane Heavy Duty Double Girder 3 Phase

Industrial 15m Gantry Crane Heavy Duty Double Girder 3 Phase
Industrial 15m Gantry Crane Heavy Duty Double Girder 3 Phase
Industrial 15m Gantry Crane Heavy Duty Double Girder 3 Phase Industrial 15m Gantry Crane Heavy Duty Double Girder 3 Phase Industrial 15m Gantry Crane Heavy Duty Double Girder 3 Phase

Large Image :  Industrial 15m Gantry Crane Heavy Duty Double Girder 3 Phase

Product Details:
Place of Origin: China (Mainland)
Brand Name: Dowellcrane
Certification: ISO CE BV CCC GOST SGS
Model Number: MG
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: USD 23000-100000 SET
Packaging Details: Main body packaged by high quality water-proof plastic woven cloths; spare parts are packed in high quality plywood box.
Delivery Time: 35 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 Sets per Year

Industrial 15m Gantry Crane Heavy Duty Double Girder 3 Phase

Description
Span: 3~40m Cantilever Length: 0-15m
Rated Lifting Moment: 550KN Lifting Speed: 5-15M/MIN
Trolley Running Speed: 20-40M/MIN Crane Running Speed: 30-50M/MIN
Control Method: Cabin Control/wire Rope Remote Control Power Supply: 3 Phase 380V 50hz Or Request
Work Duty: A5~A7 Control: Remote , Pendant Line , Cabin
High Light:

Industrial Gantry Crane Double Girder

,

Industrial 15m Gantry Crane

,

3 Phase Gantry Crane Heavy Duty

Industrial Heavy Duty Double Girder Gantry Crane


Industrial Heavy Duty Double Girder Gantry Crane Description



Double Beam Hook Gantry Crane consists of gantry frame steel structure, trolley, crane traveling mechanism, electrical system and other main components.
Outdoor operation gantry crane also equipped with rail clamp, weight restriction device, limit device of each mechanism, as well as various safety devices in accordance with prescribed safety procedures of cranes.
Sometimes the crane also equipped with rail clamp device, anchor device, anemometer, corrective devices, etc. as required.
Double Beam Hook Gantry Crane with hook are used for handling and lifting materials in open storage, stock ground, railway freight station, ports and so on. It can also carry out some special operations by equipped with various special lifting tools.



Industrial Heavy Duty Double Girder Gantry Crane Technical Parameters



Item
A Type Double-beam Hook Gantry Crane
Loading capacity
5~160t
Hoisting height
6~30m
Span
18~35m
Hoisting mechanism
Electric winch trolley
Working Class
A5
Power supply
380V 50Hz 3Ph or custom made



Industrial Heavy Duty Double Girder Gantry Crane Drawing

Industrial 15m Gantry Crane Heavy Duty Double Girder 3 Phase 0



Gantry Crane Details



Industrial 15m Gantry Crane Heavy Duty Double Girder 3 Phase 1



Advantages Industrial Heavy Duty Double Girder Gantry Crane



  • This gantry crane own the performance of low expense, high performance, easy to operate and maintenance and so on.
  • All hoist and crane movements are independent and can be run simultaneously different design duo to meet crane applications,
  • Flexible solution for all lifting needs.
  • Excellent driving properties, frequency control, smoothly moving.
  • End carriage equipped with anti-friction bearings, crane buffer block, derailment protectors.



Safety Devices



  1. Overload protection;
  2. Main lifting motor with thermal protection;
  3. Hooks with latch;
  4. Protective earthing;
  5. Crane switch and travel end switch;
  6. Emergency switch can stop all movement when any dangerous happened;
  7. All cranes must be preassembled and tested before leaving factory and offer the certification of test.




Package & Delivery



  1. Hoist and electric parts will be packed by plywood crate, for avoiding the demage from goods crash and impact during the delivery.
  2. Girders and other main parts will be packed by plastic woven cloth, for preventing rust from soppy condition during the transportation.
  3. Only the best transport solution will be taken for saving your cost uttermost on finance, security and time.



Industrial 15m Gantry Crane Heavy Duty Double Girder 3 Phase 2





Our Service



1. We have a professional sales team,can privede u a quick and professional reply.
2. Exclusive engineer support at any time, so we can design within 24 hours.
3. 2 year warranty for whole machines, providing all parts free of charge.
4. Low charge for continue maintenance when warranty is expired.
5. c an produce the largest tonnage crane,just give us your demand.
6. We can provide free training to end-users, don't worry about the installation.
