Motorized Gantry Crane 550KN Double Girder Goliath

Motorized Gantry Crane 550KN Double Girder Goliath
Motorized Gantry Crane 550KN Double Girder Goliath
Motorized Gantry Crane 550KN Double Girder Goliath Motorized Gantry Crane 550KN Double Girder Goliath Motorized Gantry Crane 550KN Double Girder Goliath

Large Image :  Motorized Gantry Crane 550KN Double Girder Goliath

Product Details:
Place of Origin: China (Mainland)
Brand Name: Dowellcrane
Certification: ISO CE BV CCC GOST SGS
Model Number: MG
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: USD 23000-100000 SET
Packaging Details: Main body packaged by high quality water-proof plastic woven cloths; spare parts are packed in high quality plywood box.
Delivery Time: 35 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 Sets per Year

Motorized Gantry Crane 550KN Double Girder Goliath

Description
Span: 3~40m Cantilever Length: 0-15m
Rated Lifting Moment: 550KN Lifting Speed: 5-15M/MIN
Trolley Running Speed: 20-40M/MIN Crane Running Speed: 30-50M/MIN
Control Method: Cabin Control/wire Rope Remote Control Power Supply: 3 Phase 380V 50hz Or Request
Work Duty: A5~A7 Control: Remote , Pendant Line , Cabin
High Light:

Motorized Goliath Gantry Crane

,

550KN Gantry Crane

,

Motorized Gantry Crane Double Girder

3 Years After-sales Warranty Motorized Double Girder Goliath Gantry Crane


3 Years After-sales Warranty Motorized Double Girder Goliath Gantry Crane Description



Double girder gantry crane is suitable for loading, unloading and handling of mines, port terminals, railway freight stations, open storage warehouses, etc., and can be equipped with a variety of spreaders (grabs, electromagnets, C-hooks, etc.) for operation. The rails of double girder gantry cranes are installed on the ground, and the main beam is supported by the legs. The rails of the bridge crane are installed on the column without the legs. It is the biggest difference between the double girder bridge cranes and double girder gantry cranes.



3 Years After-sales Warranty Motorized Double Girder Goliath Gantry Crane Technical Parameters



Item
China Manufacturing Customized Double Girder Gantry Crane
Loading capacity
5~160t
Hoisting height
6~30m
Span
18~35m
Hoisting mechanism
Electric winch trolley
Working Class
A5
Power supply
380V 50Hz 3Ph or custom made



3 Years After-sales Warranty Motorized Double Girder Goliath Gantry Crane Drawing

Motorized Gantry Crane 550KN Double Girder Goliath 0



Gantry Crane Details



Motorized Gantry Crane 550KN Double Girder Goliath 1



Advantages of 3 Years After-sales Warranty Motorized Double Girder Goliath Gantry Crane



  • Advanced technology, delicate design, attractive appearance
  • Novel structure, wide span, high crane stability and reliability
  • Large loading capacity and high working efficiency
  • Flexible operation and easy maintenance
  • Standardization, generalization and serialization of the spare parts.



Quality Insurance



  1. Strict weld inspection process
  2. Strictly control the size of each item
  3. Strict production and process control, QC inspection control
  4. All four corners are strictly polished
  5. Cover and protect some parts before painting to ensure the quality of painting
  6. The entire crane is pre-assembled and tested before delivery to ensure that the crane is free of dimensional errors and quality issues



Package & Delivery



  1. Hoist and electric parts will be packed by plywood crate, for avoiding the demage from goods crash and impact during the delivery.
  2. Girders and other main parts will be packed by plastic woven cloth, for preventing rust from soppy condition during the transportation.
  3. Only the best transport solution will be taken for saving your cost uttermost on finance, security and time.



Motorized Gantry Crane 550KN Double Girder Goliath 2





Our Service



1. We have a professional sales team,can privede u a quick and professional reply.
2. Exclusive engineer support at any time, so we can design within 24 hours.
3. 2 year warranty for whole machines, providing all parts free of charge.
4. Low charge for continue maintenance when warranty is expired.
5. c an produce the largest tonnage crane,just give us your demand.
6. We can provide free training to end-users, don't worry about the installation.

Notice

If you want to order this double beam gantry crane, Pls tell me the details as follows:
  • The Max lifting capacity? (Ton)
  • The span of gantry crane?(the distance of rail to rail center)
  • Do you need cantilevers at two beam ends? if it is, Pls mention the length per side.
  • The Max. lifting height of hook? (or total height of crane?)
  • What type meterial will you to lift?
  • The power source standard?(380V, 50Hz, 3phase or others)
