Single Girder Mobile LD Overhead Crane Wireless Remote Control Lift Goods 30m

Single Girder Mobile LD Overhead Crane Wireless Remote Control Lift Goods 30m
Single Girder Mobile LD Overhead Crane Wireless Remote Control Lift Goods 30m
Single Girder Mobile LD Overhead Crane Wireless Remote Control Lift Goods 30m Single Girder Mobile LD Overhead Crane Wireless Remote Control Lift Goods 30m Single Girder Mobile LD Overhead Crane Wireless Remote Control Lift Goods 30m Single Girder Mobile LD Overhead Crane Wireless Remote Control Lift Goods 30m

Large Image :  Single Girder Mobile LD Overhead Crane Wireless Remote Control Lift Goods 30m

Product Details:
Place of Origin: China (Mainland)
Brand Name: Dowellcrane
Certification: SGS IOS CE
Model Number: LD
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $1000-15000/set
Packaging Details: packed by plywood crate or plastic woven cloth
Delivery Time: 60days
Payment Terms: L/C, T/T,
Supply Ability: 1000 Sets per Month

Single Girder Mobile LD Overhead Crane Wireless Remote Control Lift Goods 30m

Description
Product Name: Overhead Crane Single Girder Span: 10.5-31.5m
Condition: New Warranty: 2 Years
Max. Lifting Height: 30m Feature: Other
Application: Construction,Workshop,Factory Certification: ISO CE
High Light:

Single Girder Mobile LD Overhead Crane

,

LD Overhead Crane Wireless Remote Control

,

30m LD Overhead Crane

Wireless Remote Control Lift Goods Mobile Overhead Crane Single Girder



Overhead Crane Single Girder Description



LDA model single girder overhead crane is characterized by more reasonable structure and higher strength steel as a whole.
Used together with CD1 model MD1 model electric hoist as a complete set, it is a light duty crane with a capacity 1 ton ~ 32 tons. The span is 7.5m~ 31.5m. Working grade is A3~A4.
This product is widely used in plants, warehouse, material stocks to lift goods. It is prohibited to use the equipment in the combustible, explosive or corrosive environment.
This product has two operational methods, ground or operational room which has open model closed model and can be installed on the left or right side according to the practical situation.
And the direction of entering the gate has two forms, sideway and ends in order to satisfy the users, choice under different conditions.



Overhead Crane Single Girder Parameters



Capacity
T
1,2,3,5,10
16,20



Span
m
7.5-22.5
7.5-22.5
Lifting height
m
6,9,12,18,24,30
12,18,24,30
Lifting speed
m/min
8,8/0.8,7/07
3.5,3.5/0.35
Cross travel speed
m/min
20,30
20,30
Long travel speed
m/min
20,30,45,60,75
20,30,45,60,75
Electric hoist
type
CD/MD
CD/MD/HC
Working duty

A3
A3
Power supply
AC
380V/50HZ/3P
380V/50HZ/3P



Overhead Crane Single Girder Main Features



1. Heavy Duty and High Efficient;
2. Suitable for any environment ( High Temperature, Explosion Proof and so on);
3. Long Life Span: 30-50years;
4. Easy for Installation and maintenance;
5. Reasonable structure and strong rigidity;
6. The speed can be frequency inverter speed control;
7. Control method is cabin control or remote control;



Advantages of Overhead Crane Single Girder

  1. Strong box type,U-shape groove of main beam is manufactured by one time forming machine,no weld,strong and nice looking.
  2. Rib plate is welded by robot group,high efficiency,high quality and strong bearing capacity,long service life
  3. End beam U shape groove is also bended by one time forming machine,welding is done by robot.
  4. Six action direction movement, to get enough working area.
  5. Motor protection class IP44,IP54,IP55
  6. Frequency inverter is optional for speed control.



Part of  Overhead Crane Single Girder

Single Girder Mobile LD Overhead Crane Wireless Remote Control Lift Goods 30m 0



Package and Delivery



Single Girder Mobile LD Overhead Crane Wireless Remote Control Lift Goods 30m 1



FAQ



Q. What's the information should I provide when inquiry?

More details or drawings, better.

A: Lift capacity

B: span

C: lift height

D: power source or other specials you give us will be more appreciated.


Q. How many operating methods for my selection?

Standard operating methods:

A: pendent controller with push buttons .

B: remote control with push buttons

C: cabin(space capsule seat) control with joystick


Q. Safety device

A:Overload limiter

B:Limit Switch (lifting and traveling)

C:Interlock protection device.
