Product Details:
|
| Product Name: | Electric Hoist | After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Field Maintenance And Repair Service,Free Spare Parts |
|---|---|---|---|
| Lifting Capacity: | 0.5T~30T | Control Method: | Remote Control |
| Color: | Customized | Ambient Temperature: | -20℃~+40℃ |
| Usage: | Construction Hoist, Mining Hoist, Material Handling, Portable, Household | Lifting Speed: | 0.8/8M/Min |
High Performance Industrial Using Electric Hoist For Heavy Loads
Electric Hoist is designed for construction hoist, mining hoist, material handling and household usage. It is remote controlled and wireless remote control hoist, which is safe and reliable with overload protection device and limit switch. This Electric Hoist has lifting capacity from 0.5T to 30T and can be used in ambient temperature from -20℃ to +40℃, which makes it suitable for indoor and outdoor use. It is also an overhead electric hoist with multiple security measures, such as overload protection, emergency stop and safety limit switch. With its strong and durable design, it is perfect for any application that requires reliable and safe hoisting.
|
Very Popular Vertical Lifting Wire Rope Electric Cable Hoist Winch
|
||||||||
|
Model
|
CD/MD
0.25t
|
CD/MD
0.5t
|
CD/MD
1t
|
CD/MD
2t
|
CD/MD
3t
|
CD/MD
4t
|
CD/MD
5t
|
|
|
Lifting Weight
|
0.25
|
0.5
|
1
|
2
|
3
|
5
|
10
|
|
|
Lifting Height(m)
|
3-9
|
6-12
|
6-30
|
6-30
|
6-30
|
6-30
|
6-30
|
|
|
Lifting Speed(m/min)
|
8(8/0.8)
|
8(8/0.8)
|
8(8/0.8)
|
8(8/0.8)
|
8(8/0.8)
|
8(8/0.8)
|
7(7/0.7)
|
|
|
Running Speed
|
20(30) m/min
|
|||||||
|
Wire Rope Model
|
6×19-3.6
|
6×37-4.8-180
|
6×37-7.4-180
|
6×37-11-155
|
6×37-13-170
|
6×37-15-200
|
6×37-15-200
|
|
|
I-beam Track Model
|
16-22b
|
16-28b
|
16-28b
|
20a-32c
|
20a-32c
|
25a-63c
|
28a-63c
|
|
|
Minimum radius of circular orbit(m)
|
0.8
|
1.5
|
1.5-4
|
2-4
|
2-4
|
2.5-5
|
3.5-9
|
|
|
Lifting Motor
|
Motor
|
ZD12-4
|
ZD21-4
|
ZD22-4
|
ZD31-4
|
ZD41-4
|
ZD41-4
|
ZD51-4
|
|
ZDS0.2/1.5
|
ZDS0.2/1.5
|
ZDS0.4/3
|
ZDS0.4/4.5
|
ZDS0.8/7.5
|
ZDS1.5/13
|
|||
|
Capacity
|
0.4
|
0.8 0.2/0.8
|
1.5 0.2/1.5
|
3 0.4/3
|
4.5 0.4/4.5
|
7.5 0.8/7.5
|
13 1.5/13
|
|
|
rotation rate
|
1380
|
1380
|
1380
|
1380
|
1380
|
1400
|
1400
|
|
|
Power supply
|
3P 380V 50HZ
|
|||||||
The Remote controlled Electric Hoist from Dowell Crane is a great choice for a variety of applications, including Construction Hoist, Mining Hoist, and Material Handling purposes. The model is CD MD and it is ISO and CE certified. With a minimum order quantity of 1 Set, the price of the Electric Hoist ranges from US$350.00 to US$6,450.00. The Electric Hoist is packed by water-proof film, and the spare parts are packed by high quality plywood box. The delivery time is 15 days, and the payment terms are L/C, T/T, Western Union. The Dowell Crane Electric Hoist has a Supply Ability of 200 Set/Sets per Month. The After-sales Service includes Engineers Available To Service Machinery Overseas, Field Maintenance And Repair Service, and Free Spare Parts. The Ambient Temperature for the Electric Hoist is -20℃~+40℃, and it is controlled by Remote Control.
Electric Hoist Technical Support and Service
We offer comprehensive technical support and service for our Electric Hoist products. Our team of experienced engineers is available to answer any questions you may have and provide advice on installation, operation, and troubleshooting. We also provide maintenance and repair services. Our service technicians are available to help you keep your equipment running smoothly and efficiently.
If you need assistance with your Electric Hoist, please contact us and our team will be happy to help.
Packaging of Electric Hoist: The electric hoist should be packaged in a sturdy box, with the description of the product clearly labeled. Bubble wrap should be used to cushion the electric hoist during shipping.
Shipping of Electric Hoist: The electric hoist should be shipped via a reliable shipping service. The package should be tracked and insured to ensure safe delivery.
