Product Details:
|
| Product Name: | European Standard Single Girder Bridge Crane | Span: | 7.5-31.5 M |
|---|---|---|---|
| Control Method: | Cabin/Remote Control | Working Temperature: | -25℃~40℃ |
| Working Class: | A3-A7 | Trolley Speed: | 20-40 M/min |
| Power Supply: | 3-Phase AC 380V/50Hz | Lifting Height: | 6-30 M |
European Standard Single Girder Bridge Crane Power Supply 20-40 M/Min Speed
Single Girder Eot Crane is an overhead lifting equipment made in accordance with European standard. It is a type of overhead crane with a single girder and electric hoist as the lifting mechanism. It is designed for general service in workshops, warehouses, assembly shops and other light-duty industrial applications. With a capacity ranging from 1 to 50 Ton, a power supply of 3-Phase AC 380V/50Hz, and a span ranging from 7.5 to 31.5 M, this overhead lifting equipment can meet most of your needs. It is highly efficient, providing reliable performance, excellent safety, and easy maintenance. The crane is designed to comply with the latest safety regulations and provides excellent lifting capacity and stability. With its flexible operation, it can be used for a variety of applications, including loading, unloading, transferring and lifting, making it an ideal choice for overhead lifting.
| Capacity | t | 1,2,3,5,10 | 16,20 | |
| Span | m | 7.5-22.5 | ||
| Lifting height | m | 6,9,12,18,24,30 | 12,18,24,30 | |
| Speed | Lifting | m/min | 8,8/0.8,7/07 | 3.5,3.5/0.35 |
| Cross travel | m/min | 20,30 | 20,30 | |
| Long travel | m/min | 20,30,45,60,75 | ||
| Electric hoist | type | CD/MD | CD/MD/HC | |
| Working duty | A3 | A3 | ||
| Power supply | AC | 380V/50HZ/3P | 380V/50HZ/3P | |
Dowell Crane's Single Girder Eot Crane is designed for European-style overhead crane applications. It is equipped with a 3-phase AC 380V/50Hz power supply and is capable of wire rope hoisting. It has a span of 7.5-31.5 m and is available in a variety of colors. This reliable and durable crane is certified by ISO, CE, BV, CCC, and GOST. It is a perfect solution for various industrial operations.
The minimum order quantity for Dowell Crane's Single Girder Eot Crane is one set and the price ranges from USD 6000-12000 per set. It is shipped in a stretch film and plywood case for extra protection. Delivery takes 25 days and payments can be made both through L/C and T/T. The company can supply up to 10000 sets of this crane per year.
Our Single Girder EOT Crane is a type of Electrical Overhead Travelling Crane, European type overhead crane, designed to meet the requirements of all types of industrial lifting applications. It is the perfect solution for lifting loads & controlling movement, making it ideal for a variety of applications such as manufacturing, maintenance, warehouses, ports, and more.
This crane is designed to provide maximum reliability, safety, and efficiency. It is equipped with advanced safety features including overload protection, emergency stop, and adjustable working speed. The crane has a capacity of 1-50 ton, with a speed range of 20-40m/min for the crane and 7-20m/min for the hoist.
This crane is easy to operate and maintain, with a power supply of 3-Phase AC 380V/50Hz and control method of either cabin or remote. It has a certification of ISO CE BV CCC GOST, and a minimum order quantity of 1 set. The price ranges from USD 6000-12000/set, with a delivery time of 25 days.
Dowell Crane is your reliable partner for Single Girder EOT Crane and other Electrical Overhead Travelling Cranes.
We provide technical support and service for Single Girder Eot Crane. We have professional technicians to help you solve technical problems. Our technicians have rich experience and can provide you with the most professional service. We can provide you with technical advice, maintenance service, installation service, training service and so on. If you have any questions about our Single Girder Eot Crane, please feel free to contact us. We will be more than happy to help.
Packaging and Shipping of Single Girder Eot Crane:
1. The crane parts will be packed in wooden cases, with the outside of the cases marked with the company logo, product name, and product model.
2. The crane will be shipped by land, sea, or air freight, depending on the customer’s requirements.
3. The crane will be shipped with all necessary documents, such as installation and operating instructions, safety warnings, and warranty information.
Q1: What is the brand name of the Single Girder Eot Crane ?
A1: The brand name of the Single Girder Eot Crane is Dowell Crane.
Q2: What is the model number of the Single Girder Eot Crane ?
A2: The model number of the Single Girder Eot Crane is EOT European Style Overhead Crane.
Q3: Where is the Single Girder Eot Crane from ?
A3: The Single Girder Eot Crane is from China (Mainland).
Q4: What certifications do the Single Girder Eot Crane have?
A4: The Single Girder Eot Crane have ISO CE BV CCC GOST certifications.
Q5: How much is the Single Girder Eot Crane ?
A5: The price of the Single Girder Eot Crane is USD 6000-12000 /Set.
